Equipment Advantages

• High Speed Process

  High speed mechanical drive for filter plate shift during open and close, up to 3 times faster than standard hydraulic cylinder system

• Compact Design

  Not necessary to have hydraulic cylinder with long stroke to open and close the plate. Space required decreased more than 20 %.

• Fully automatic operation with traveling filter cloth system

  Even very thin filter cakes of 2-3 mm are automatically discharged and all filter cloth are washed simultaneously.

• Effective and efficient cake washing

  Top feeding port is adapted for excellent cake wash performance

• Large Capacity Available

  Filtration area; from 109㎡ to 800㎡
  Compression pressure; from 0.7MPa to 2.0MPa
